| Production enterprise information |
| Vehicle name: | Dongfeng 8-10CBM Compress Garbage Truck | Vehicle type: | Special vehicleLaws and regulations |
| Manufacturing place: | China | Type of licence: | The vehicle license plate classification standard |
| Announcement batch: | 275 | Release date: | 20150812 |
| product ID: | ZJZHU4WP081 | Directory number: | (Seventeen)74 |
| Chinese brand: | CLW GROUP TRUCK | English brand: |
|
| Announcement type: | CLW5120ZYST4 | Exempt from: | yes |
| Enterprise name: | CLW GROUP TRUCK | fuel: | no |
| Business address: | The southern suburbs of Hubei Province, Suizhou city Zengdou District Chengli Automobile Industry Park | environmental protection: | no |
| Inspection instructions |
| Exemption: | no | Check the inspection period: |
|
| Announcement status |
| Announcement status: | effective | Effective date of announcement: | 20150812 |
| Announcement state description: | change | change(extend)Record: | 247 |
| Main technical parameters |
| Outline dimension: | 8170,7760,7920,7510*2490*3250(mm) | Cargo compartment size: | * *(mm) |
| Total mass: | 12450(Kg) | Load quality utilization factor: | 0 |
| curb weight: | 7655(Kg) | Rated load quality: | 4600(Kg) |
| Trailer quality: | (kg) | Semitrailer saddle: |
|
| Cab: |
| Front passenger: | 3(people) |
| Rated capacity: | (people) | Anti lock braking system: | Yes |
| Approach angle/Departure angle: | 30/21,30/22,30/23,30/24(DEG) | The front suspension/Rear overhang: | 1250/2720,1250/2560, 1250/2470,1250/2310(mm) |
| Axle load: | 4750/7700 | Wheelbase: | 3950,4200(mm) |
| Axis number: | 2 | Maximum speed: | 90(km/h) |
| Oil consumption: | 24.3,24.3,24.2,23.9,24.0,23.9,23.9 | Spring sheet number: | 8/11+8 |
| Tyre number: | 6 | Tire specifications: | 9.00-20 14PR,9.00R20 14PR |
| Front track: | 1900,1810 | Rear wheel: | 1800 |
| Brake front: |
| After braking: |
|
| Before system operation: |
| After the operation of the system: |
|
| Steering form: | Steering wheel | Starting method: |
|
| drive system: |
| Oil consumption(L/100Km): | 24.3,24.3,24.2,23.9, 24.0,23.9,23.9 |
| VinVehicle identification code: | LGHXCD1HX x x x x x x x x x x x
LGHXCD1KX x x x x x x x x x x x
LGHXCG1HX x x x x x x x x x x x
LGHXCG1KX x x x x x x x x x x xLaws and regulations |
| Engine parameters |
| Engine | Engine production enterprise | displacement(ml) | power(kw) |
YC4E160-42
ISDe160 40
ISB170 40
YC6J160-46 | Guangxi Yuchai Machinery Limited by Share Ltd
Dongfeng Cummins Engine Co., Ltd.
Dongfeng Cummins Engine Co., Ltd.
Guangxi Yuchai Machinery Limited by Share Ltd | 4260
4500
5900
6494 | 118
118
125
118 |
| Vehicle fuel parameters |
| Fuel type: | diesel oil | Based on standard: | |
| Chassis emission standard: | GB3847-2005,GB17691-2005countryIV |
| Other |
| Optional no tilting mechanism of the car. When the vehicle has a rear turnover mechanism,Vehicle length8170mmWhen the corresponding wheelbase4200mmThe corresponding rear suspension2720mm,Vehicle length7760mmWhen the corresponding wheelbase3950mmThe corresponding rear suspension2560mm. The car without turning mechanism,Vehicle length7920mmCorresponding base4200mmThe corresponding rear suspension2470mm,Vehicle length7510mmCorresponding base3950mmThe corresponding rear suspension2310mm. Left and right side and rear protective materialQ235ACarbon steel welded connection,Back protection is replaced by a special device,The lower plane is high from the ground400mm. Chassis with optional front bumper and lamps. Installation with satellite positioning function driving recorder.ABSManufacturer:Dongfeng electronic Polytron Technologies Inc brake system company;Model:3631010-C2000. Optional concave plane box style. |
| Reflective marking parameters |
| Marking enterprise: | CLW GROUP TRUCK | Logo mark: | CLW GROUP TRUCK |
| Identification model: | TM1200-1,HW1400 |
